Outdoor patrol thermal scope monocular new scope infrared night vision telescopeTracer LRF thermal imagers are equipped with a built-in laser rangefinder with a range of up to 1000 m and measurement accuracy of ± 1 m. High sensitive thermal image Vox sensor with NETD 35mK allows you to detect targets by cutting through sn

Featured Products

Outdoor patrol thermal scope monocular new scope infrared night vision telescope

Tracer LRF thermal imagers are equipped with a built-in laser rangefinder with a range of up to 1000 m and measurement accuracy of ± 1 m. High sensitive thermal image Vox sensor with NETD 35mK allows you to detect targets by cutting through snow, dust, smoke, fog, haze, and other atmospheric obscurants.They can be used in various applications including hunting, observation, security, terrain orientation, search and rescue operations, etc.
Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
Key Features:

Ergonomic design
High sensitive thermal image sensor
IP67
Built-in laser rangefinder
Detection Range
Wifi and on-board recording

Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope

 TracerLRF 35TracerLRF50
Detector
TypeUncooled Vox
Resolution384×288
Frame rate50Hz
Pitch17μm
Spectral range8-14μm
NETDLess than 35mk
Optical Characteristics
Objective lens35mm50mm
Magnification2.7x3.9x
FOV10.6°×8.0°7.4°×5.6°
Close-up range5m
Dioptre adjustment-5D-4D
Functions
ZoomSmooth digital zoom
Palette5 optional(can be customized)
Start up timeLess than 5 seconds
Start up imageCan be customized
Menu and informationGUI(Can be customized)
Image enhancementDDE
Contrast and brightnessAGC
Online updateBoth code and GUI resources
Display
TypeOLED
Resolution1024×768
Power Supply
BatteryBuilt-in lithium battery
External power supply5V micro USB
Battery life8h+
Physical Characteristics
Weight without battery540g590g
Size155x50x92mm165x56x92mm
Environmental Compatibility
Water proofIP67
Operating temperature-20ºC-50ºC
Storage temperature-40ºC-60ºC
Laser Rangefinder
Safety class for laser equipment
according to IEC 60825-1:2014
1
Measuring range5-1000m
Measurement accuracy±1m

Outdoor Patrol Thermal Scope Monocular New Scope Infrared Night Vision Telescope
FAQ

Q: Are you a trade company or a manufacturer?

A: We are an ISO approved manufacturer specialized in thermal imaging devices.
OEM & ODM service are available. Welcome to visit us.

Q : Can we be your wholesaler or distributor ?
Yes, welcome.And we will offer more reasonable price for all wholesaler, distributor, dealer, and reseller .

Q:What certificate do you have?
A:We have passed CE/ROHS/ ISO9001/SGS.And have applied design patent.

Q: Can I order one set for sample to test the quality?
A: Yes, We recommend checking the sample before order. Pls contact us for detailed price.

Q: What is your MOQ?
A: To start our cooperation, one set is acceptable.

Q: What is your payment terms?
A: Wee accept T/T bank trasnfer , western union, paypal.

Q: What is your delivery date?
A: The delivery date is about 3-15 working days after receipt of payment.

Q: How about the package?
A: Packaging, We usually use carton box for our products, we could also do any packing according to the customers's request, just please kindly let us know your idea!

Q : How about delivery ?
A: Usually we sent goods by DHL, UPS, TNT, and EMS for small package and by Air or by Sea for big volume.

Q: Do you have a warranty?
A: Yes, we have the warranty of 24 months.
